Home

Welcome to the complete developer documentation for the Woodev Plugin Framework. This manual provides comprehensive guidance for building WooCommerce plugins using the Woodev framework.

What is Woodev Framework?

Woodev Framework is a scaffold for developing WooCommerce plugins. It handles infrastructure concerns so that each plugin can focus on business logic. The framework provides:

• Unified plugin bootstrap and lifecycle management
• Dependency checking (PHP, WordPress, WooCommerce)
• Admin pages and settings infrastructure
• REST API integration
• Shipping method and payment gateway base classes
• Background job processing
• HPOS (High-Performance Order Storage) compatibility
• WooCommerce Blocks compatibility

Quick Start

1. Register Your Plugin

In your main plugin file:

<?php
/**
 * Plugin Name: My Plugin
 * Plugin URI: https://example.com/my-plugin
 * Description: My WooCommerce plugin
 * Version: 1.0.0
 * Author: Your Name
 * Text Domain: my-plugin
 * Requires at least: 5.9
 * Requires PHP: 7.4
 * WC requires at least: 5.6
 */

defined( 'ABSPATH' ) || exit;

// Include the bootstrap file
if ( ! class_exists( 'Woodev_Plugin_Bootstrap' ) ) {
    require_once plugin_dir_path( __FILE__ ) . 'woodev/bootstrap.php';
}

// Initialize the plugin
add_action( 'plugins_loaded', 'init_my_plugin', 0 );

function init_my_plugin() {
    Woodev_Plugin_Bootstrap::instance()->register_plugin(
        '1.4.0',  // Framework version
        'My Plugin',
        __FILE__,
        'my_plugin_init',
        [
            'minimum_wc_version'   => '8.0',
            'minimum_wp_version'   => '5.9',
            'backwards_compatible' => '1.4.0',
        ]
    );
}

function my_plugin_init() {
    final class My_Plugin extends Woodev_Plugin {}
    return My_Plugin::instance();
}

2. Create Your Plugin Class

<?php
class My_Plugin extends Woodev_Plugin {

    private static $instance;

    public static function instance(): self {
        if ( null === self::$instance ) {
            self::$instance = new self();
        }
        return self::$instance;
    }

    public function __construct() {
        parent::__construct(
            'my-plugin',
            '1.0.0',
            [ 'text_domain' => 'my-plugin' ]
        );
    }

    public function get_file(): string {
        return __FILE__;
    }

    public function get_plugin_name(): string {
        return __( 'My Plugin', 'my-plugin' );
    }

    public function get_download_id(): int {
        return 0;
    }
}

Documentation Structure

Getting Started

Document	Description
Getting Started	Installation, requirements, and architecture overview
Core Framework	Bootstrap, plugin base class, lifecycle management

Core Modules

Document	Description
Admin Module	Admin pages, notices, and message handlers
Settings API	Typed settings framework
Helpers	Utility functions and helpers

API & Integration

Document	Description
API Module	HTTP client base classes
REST API	REST endpoints and system status integration

Specialized Plugins

Document	Description
Shipping Method	Building shipping plugins
Payment Gateway	Building payment gateway plugins
Box Packer	Product packing algorithms for shipping

Utilities & Compatibility

Document	Description
Utilities	Background jobs and async requests
Compatibility	HPOS and WooCommerce version compatibility
Handlers	Blocks and script handlers

Framework Architecture

woodev/
├── bootstrap.php                # Singleton bootstrap loader
├── class-plugin.php             # Woodev_Plugin abstract base class
├── class-lifecycle.php          # Install / upgrade lifecycle handler
├── class-helper.php             # Static utility helpers
├── class-admin-notice-handler.php  # Dismissible admin notices
├── class-admin-message-handler.php # Flash message handler
├── admin/                       # Admin pages (Licenses, Plugins)
├── api/                         # HTTP API base classes
├── box-packer/                  # Box packing algorithm abstractions
├── compatibility/               # HPOS and WooCommerce compatibility
├── handlers/                    # Gutenberg blocks handler
├── rest-api/                    # Settings REST API integration
├── settings-api/                # Typed settings framework
├── shipping-method/             # Shipping plugin and method base classes
├── payment-gateway/             # Payment gateway base classes
└── utilities/                   # Background job queue

Key Concepts

Plugin Bootstrap

The Woodev_Plugin_Bootstrap singleton ensures only one version of the framework is loaded, even when multiple plugins bundle different versions. It selects the highest registered framework version and initializes all compatible plugins.

Plugin Lifecycle

1. Registration — Plugin calls register_plugin() with framework version
2. Bootstrap — Highest framework version is loaded at plugins_loaded priority 0
3. Initialization — Plugin factory callback creates plugin instance
4. Setup — Plugin hooks into WordPress and WooCommerce actions
5. Lifecycle — Install, upgrade, activation, deactivation routines

Dependency Management

The framework automatically checks:

• PHP extensions (curl, json, mbstring, etc.)
• PHP functions (gzinflate, base64_decode, etc.)
• PHP settings (allow_url_fopen, max_execution_time, etc.)
• WordPress version
• WooCommerce version

HPOS Compatibility

All plugins should declare HPOS support:

<?php
parent::__construct(
    'my-plugin',
    '1.0.0',
    [
        'supported_features' => [
            'hpos' => true,
        ],
    ]
);

Blocks Compatibility

Declare compatibility with WooCommerce Cart and Checkout blocks:

<?php
parent::__construct(
    'my-plugin',
    '1.0.0',
    [
        'supported_features' => [
            'blocks' => [
                'cart'     => true,
                'checkout' => true,
            ],
        ],
    ]
);

Recommended Reading Order

For developers new to Woodev Framework:

1. Getting Started — Understand the architecture
2. Core Framework — Learn the plugin base class
3. Settings API — Add plugin settings
4. Admin Module — Create admin pages
5. Helpers — Use utility functions
6. Utilities — Implement background processing
7. Compatibility — Ensure HPOS compatibility
8. API Module — Make HTTP requests
9. REST API — Expose plugin data via REST
10. Shipping Method or Payment Gateway — Build specialized plugins

Support

• Documentation: kalbac.github.io/woodev-plugin-framework
• Woodev website: woodev.ru
• Plugin shop: woodev.ru/shop
• Support desk: woodev.ru/support

Version Information

Component	Version
Framework	1.4.1
Minimum PHP	7.4
Minimum WordPress	5.9
Minimum WooCommerce	5.6

---

This documentation is part of the Woodev Plugin Framework. For updates and additional resources, refer to the framework repository.
